| Mixing capability |
Mixing channels |
32 Line Inputs (24 mono and 4 stereo) |
| GROUP |
4 GROUP Buses + ST Bus |
| AUX |
6 AUX Sends + 2 FX Sends |
| MATRIX |
1 Matrix out |
| On-board processors |
FX1:REV-X(8 PROGRAM, PARAMETER control)/ FX2:SPX(16 PROGRAM, PARAMETER control) |
| I/O |
Mic inputs |
MIC: 24 (INPUTS HPF: 100Hz 12dB/oct) |
| Phantom power |
48V phantom power per channel |
| Line inputs |
LINE: 24 mono + 4 stereo, CH INSERT: 24 RETURN: 1 stereo |
| Digital I/O |
USB Device, iPod / iPhone |
| Total harmonic distortion |
0.02% (20Hz-20kHz@ +14dBu) |
| Frequency response |
+0.5/-1.0dB 20Hz - 20kHz, refer to the nominal output level @1kHz |
| Hum & noise level |
Equivalent input noise |
-128 dBu Equivalent Input Noise |
| Residual output noise |
-94 dBu Residual Output Noise |
| Crosstalk |
-74dB @ 1kHz |
| Power requirements |
100-240V 50Hz/60Hz |
| Power consumption |
86W max |
| Dimensions(W*H*D) |
1,027mm *169mm *565mm |
| Net weight |
19kg (41.9lb) |
