SPECIFICATIONS	AD-S282H & AD-S282HT
Configuration	Compact two way, ported enclosure
Transducers   Low Frequency Transducer   High Frequency Transducer	Dual 8" high power, treated paper cone, 2" voice coil, neodymium magnet 1" high output compression driver
Frequency Range 1   Frequency Response (-6 dB)   Useable Frequency Range (-10 dB)	80 Hz - 27.7 kHz 60 Hz - 29.5 kHz
Maximum Output (SPL at 1 m) 2   Fullrange (passive mode)   LF (biamp mode)   HF (biamp mode)	Continuous  Peak 120 dB 126 dB 124 dB 130 dB 121 dB 127 dB
Nominal Impedance   Passive   LF   HF	8 ohms 8 ohms 8 ohms
Power Rating 3   Passive   LF   HF	450 W (IEC 8 hours) 500 W (IEC 8 hours, 50 Hz - 2 kHz) 45 W (IEC 8 hours, 2 kHz - 20 kHz)
Recommended Max Amp Power (Passive)	900 W RMS
Sensitivity (SPL, 1 W at 1 m) 4   Passive   LF   HF	93 dB (100 Hz - 10 kHz) 97 dB (200 Hz - 2 kHz) 104 dB (2 kHz - 10 kHz)
Nominal Coverage	90° H x 60° V (-6 dB) (rotatable to 60° H x 90° V)
Bass Loading	Ported, tuned to 60 Hz
Transformers
Type	Custom low distortion laminated core, wide bandwidth design
Taps	70V 200, 100, 50, 25 Watts 100V 200, 100, 50 Watts
Bypass	8 ohm bypass on AD-S282HT
Enclosure
Material	Injection molded, weather resistant, high impact polystyrene
Finish	White or black (paintable)
Weather Resistance	Yes
Grill	Heavy duty powder coated aluminum
Connectors	Barrier Strip, (switchable: passive/active on AD-S282H)
Mounting Hardware	Yoke Mount (included)
Weight	27.7 lb (12.6 kg) net 35.6 lb (16.1 kg) shipping
