SPECIFICATIONS
|
AD-S82H (high output) |
AD-S82 |
| Configuration |
Compact two way, ported enclosure |
Compact two way, ported enclosure |
Transducers
Low Frequency Transducer
High Frequency Transducer |
8" high power treated paper cone, 2" voice coil, neodymium magnet
1" high output compression driver |
8" fiberglass cone, 1 1/4" voice coil
1" titanium dome tweeter with neodymium magnet |
Frequency Range 1
Frequency Response (±3 dB)
Useable Frequency Range (-10 dB) |
80 Hz - 21 kHz
60 Hz - 22 kHz |
85 Hz - 18 kHz
65 Hz - 19 kHz |
Maximum Output 2
Continuous
Peak
|
114 dB SPL
120 dB SPL
|
111 dB SPL
117 dB SPL |
| Nominal Impedance |
8 ohms (7 ohms minimum, 135 ohms maximum) |
8 ohms (5.4 ohms minimum, 50 ohms maximum) |
| Power Capacity 3 |
240 W (IEC, 8 hours)
200 W (IEC, 100 hours)
|
110 W (IEC, 8 hours)
90 W (IEC, 100 hours) |
| Recommended Max Amp Power |
400 W RMS |
180 W RMS |
| Power Limiting |
Dynamic, full range power protection circuitry activated by signal overload conditions |
Dynamic, full range power protection circuitry activated by signal overload conditions |
| Sensitivity 4 |
90.5 dB, 1 m, free field (4pi) |
90.5 dB, 1 m, free field (4pi) |
| Nominal Coverage |
90° H x 60° V (-6 dB)
(rotatable to 60° H x 90° V) |
90° H x 60° V (-6 dB)
(rotatable to 60° H x 90° V) |
| Bass Loading |
Ported, tuned to 65 Hz |
Ported, tuned to 65 Hz |
| Transformers (available with the optional ID-8T IntelliDock mounting system) |
| Type |
Custom low distortion laminated
core, wide bandwidth design |
Custom low distortion laminated
core, wide bandwidth design |
| Taps |
70V 60, 30, 15, 7.5 Watts
100V 60, 30, 15 Watts |
70V 60, 30, 15, 7.5 Watts
100V 60, 30, 15 Watts |
| Enclosure |
| Material |
Injection molded, weather resistant,
high impact polystyrene |
| Finish |
White or black (paintable) |
| Weather Resistance |
Yes |
| Grill |
Heavy duty powder coated aluminum |
| Connectors |
Pair of concealed 5-way binding posts,
in conjunction with IntelliDock mounting/connection system |
| Mounting Hardware |
Optional AcousticDesign IntelliDock or Yoke Mount |
| Weight |
16.9 lbs (7.7 kg) net
20.3 lbs (9.2 kg) shipping |
16.2 lbs (7.4 kg) net
19.6 lbs (8.9 kg) shipping |
