| SPECIFICATIONS |
AD-S52 |
AD-S52T |
| Configuration |
Compact two way, ported enclosure |
Compact two way, ported enclosure |
Transducers
Low Frequency Transducer
High Frequency Transducer |
5.25" shielded, weather-resistant
1" neodymium tweeter |
5.25" shielded, weather-resistant
1" neodymium tweeter |
Frequency Range 1
Frequency Response (±3 dB)
Useable Frequency Range (-10 dB) |
75 Hz - 19 kHz
60 Hz - 20 kHz |
75 Hz - 19 kHz
60 Hz - 20 kHz |
Maximum Output 2
Continuous
Peak
|
104 dB SPL
110 dB SPL
|
104 dB SPL
110 dB SPL |
| Nominal Impedance |
8 ohms |
Switchable 8 ohms |
Power Rating 3
|
60 W (IEC, 100 hours)
|
60 W (IEC, 100 hours) |
| Recommended Max Amp Power |
120 W RMS |
120 W RMS |
| Sensitivity 4 |
86.5 dB, 2.83 V, 1 m, free field (4pi) |
86 dB, 2.83 V, 1 m, free field (4pi) |
| Nominal Coverage |
90° H x 90° V |
90° H x 90° V |
TRANSFORMERS
|
| Type |
n/a |
Custom low distortion laminated core, wide bandwidth design |
| Taps |
n/a |
70V 30, 15, 7.5, 3.75 Watts
100V 30, 15, 7.5 Watts |
ENCLOSURE
|
| Material |
Injection molded, weather resistant,
high impact polystyrene |
| Finish |
White or black (paintable) |
| Weather Resistance |
Yes |
| Grille |
Heavy duty powder coated aluminum |
| Connectors |
Pair of 5-way binding posts |
| Mounting Hardware |
Included ball mount assembly; available optional yoke mount |
| Weight |
15 lb. (6.8 kg) net
22 lb. (10 kg) shipping |
18 lb (8.2 kg) net
25 lb (11.4 kg) shipping |
