SPECIFICATIONS
|
AD-S32T |
Configuration |
Compact two way, ported enclosure |
Transducers
Low-frequency
High-frequency |
3" (7.6 cm) weather resistant, polypropylene cone woofer
0.75" titanium dome tweeter |
Frequency Range 1
Frequency Response (-6 dB)
Useable Frequency Range (-10 dB) |
73 Hz - 20 kHz
65 Hz - 20 kHz |
Maximum Output 2
Calculated Peak Output
Calculated Continuous Output |
105 dB SPL
99 dB SPL |
Nominal Impedance |
8 ohms switchable |
Power Rating
RMS Power Handling3
Recommended Max Amp Power
|
30 W (100 hours IEC)
60 W RMS |
Sensitivity |
85 dB, 2.83 V, 1 m, free space (4 pi) |
Nominal Coverage |
100° x 100° |
TRANSFORMERS
|
Type |
Custom low distortion laminated core, wide bandwidth design |
Taps |
70 V: 30, 15, 7.5, 3.8 W / 100 V: 30, 15, 7.5 W / 8 ohm bypass |
Environmental |
Exceeds Mil Spec 810 for humidity, salt spray and dust; IEC 60529 IP-X3 splash rating |
Agency Rating |
Transformer is Listed UL1876 |
ENCLOSURE
|
Material |
Injection molded, weather resistant high impact polystyrene |
Finish |
White or black (paintable) |
Grille |
Heavy duty powder coated aluminum |
Connectors |
Screw terminals |
Mounting Hardware |
Ball mount assembly; yoke mount bracket included |
Weight |
4 lb (1.8 kg) net
10 lb (4.5 kg) shipping (pair) |
