Mixing channels |
16 Line Inputs (8 mono and 4 stereo) |
| GROUP |
4 GROUP Buses + ST Bus |
| AUX |
2 AUX Sends + 2 FX Sends |
| Input channel functions |
Compressor CH1-8,HPF(100Hz 12dB/oct), CH EQ(MONO) ±15dB(Max.):High 8kHz shelving/ Mid 250Hz-5kHz peaking(CH1-8,13-16)/ Low 125Hz shelving, CH EQ(STEREO) ±15dB(Max.):High 8kHz shelving/ Mid 2.5kHz peaking(CH9-12)/ Low 125Hz shelving |
| On-board processors |
FX1:REV-X(8 PROGRAM, PARAMETER control), FX2:SPX (16 PROGRAM, PARAMETER control) |
| I/O |
Mic inputs |
MIC: 10 |
| Phantom power |
48V phantom power per channel |
| Line inputs |
LINE: 8mono+4stereo, CH INSERT: 8, RETURN: 1stereo, 2TR IN: 1 stereo |
| Digital I/O |
USB Audio USB IN: iPod, iPhone exclusive |
| Total harmonic distortion |
0.02% (20Hz-20kHz@ +14dBu) |
| Frequency response |
+0.5/-1.0dB 20Hz - 20kHz, refer to the nominal output level @1kHz |
| Hum & noise level |
Equivalent input noise |
-128 dBu (20Hz–20 kHz, Rs=150Ω, Input Gain = Maximum) |
| Residual output noise |
-102 dBu (20Hz–20 kHz, Rs=150Ω, Input Gain = Maximum) |
| Crosstalk |
-74dB @ 1kHz |
| Power requirements |
100-240V 50Hz/60Hz |
| Power consumption |
55W max |
| Dimensions(W*H*D) |
447mm*143mm*495mm |
| Net weight |
9.0kg |
